KdComDispatcher Class Reference

Contains implementations for KdComDispatcher::KdSendPacket() and KdComDispatcher::KdReceivePacket() functions that are executed on host side. More...

#include <kdcomdisp.h>

Inherits IKdComDispatcher.

Collaboration diagram for KdComDispatcher:

[legend]

List of all members.

Public Member Functions
	KdComDispatcher (const TCHAR *pszPipeName)
void	KdResetPacketNumbering (bool InitialSetting)
	Called internally to reset the packet numbering scheme.
void	SetKdDebuggerNotPresent (bool Value)
bool	GetKdDebuggerNotPresent ()
void	KdpSendControlPacket (ULONG PacketType, ULONG NextPacketId)
	Called internally to call a bodyless control packet (such as ACK or RETRY).
KD_RECV_CODE	KdCompReceivePacketLeader (ULONG, ULONG *pSignature, PKD_CONTEXT pContext)
unsigned	KdpComputeChecksum (const void *pBuffer, unsigned Size)
	Called to compute checksum of a data block.
KD_RECV_CODE __stdcall	KdReceivePacket (ULONG PacketType, PKD_BUFFER FirstBuffer, PKD_BUFFER SecondBuffer, PULONG PayloadBytes, PKD_CONTEXT KdContext)
	Called inside VMWARE-VMX.EXE process space with parameters unmarshalled from KdReceivePacket() call in KDVMWARE.DLL.
bool __stdcall	KdSendPacket (ULONG PacketType, PKD_BUFFER FirstBuffer, PKD_BUFFER SecondBuffer, PKD_CONTEXT KdContext)
	Called inside VMWARE-VMX.EXE process space with parameters unmarshalled from KdSendPacket() call in KDVMWARE.DLL.
virtual void	ReportProtocolVersionError (int GuestVersion, int HostVersion)
	Called by KdRpcDispatcher to report protocol version mismatch.
Private Types
enum	{ KdMaxBufferSize = 0xFA0 }
enum	{ KdMinPacketCountForSuccessfulLink = 5 }
Private Attributes
PipeServer< false, true, true >	m_Pipe
unsigned	KdCompNumberRetries
unsigned	KdCompRetryCount
unsigned	KdCompNextPacketIdToSend
unsigned	KdCompPacketIdExpected
bool	KD_DEBUGGER_NOT_PRESENT
unsigned	m_PacketsSentFromLastReset
unsigned	m_PacketsGotFromLastReset
unsigned	m_SequentialResetCount
TraceAssistant	m_TraceAssistant

---

Detailed Description

Contains implementations for KdComDispatcher::KdSendPacket() and KdComDispatcher::KdReceivePacket() functions that are executed on host side.

This class contains host-side implementations of KdSendPacket() and KdReceivePacket() functions. These methods are called by KdRpcDispatcher class via IKdComDispatcher interface.

Remarks:

See the kdxxx.h file reference for info about KdSendPacket() and KdReceivePacket().

---

Member Enumeration Documentation

anonymous enum [private]

Enumerator:

KdMaxBufferSize

anonymous enum [private]

Enumerator:

KdMinPacketCountForSuccessfulLink

---

Constructor & Destructor Documentation

KdComDispatcher::KdComDispatcher

(

const TCHAR *

pszPipeName

)

[inline]

Here is the call graph for this function:

---

Member Function Documentation

bool KdComDispatcher::GetKdDebuggerNotPresent

(

)

[inline, virtual]

Implements IKdComDispatcher.

KD_RECV_CODE KdComDispatcher::KdCompReceivePacketLeader	(	ULONG	,
		ULONG *	pSignature,
		PKD_CONTEXT	pContext
	)

Here is the call graph for this function:

unsigned KdComDispatcher::KdpComputeChecksum	(	const void *	pBuffer,
		unsigned	Size
	)			[inline]

Called to compute checksum of a data block.

void KdComDispatcher::KdpSendControlPacket	(	ULONG	PacketType,
		ULONG	NextPacketId
	)

Called internally to call a bodyless control packet (such as ACK or RETRY).

Here is the call graph for this function:

KD_RECV_CODE __stdcall KdComDispatcher::KdReceivePacket	(	ULONG	PacketType,
		PKD_BUFFER	FirstBuffer,
		PKD_BUFFER	SecondBuffer,
		PULONG	PayloadBytes,
		PKD_CONTEXT	KdContext
	)

Called inside VMWARE-VMX.EXE process space with parameters unmarshalled from KdReceivePacket() call in KDVMWARE.DLL.

Here is the call graph for this function:

void KdComDispatcher::KdResetPacketNumbering

(

bool

InitialSetting

)

[inline]

Called internally to reset the packet numbering scheme.

bool __stdcall KdComDispatcher::KdSendPacket	(	ULONG	PacketType,
		PKD_BUFFER	FirstBuffer,
		PKD_BUFFER	SecondBuffer,
		PKD_CONTEXT	KdContext
	)

Called inside VMWARE-VMX.EXE process space with parameters unmarshalled from KdSendPacket() call in KDVMWARE.DLL.

Here is the call graph for this function:

void KdComDispatcher::ReportProtocolVersionError	(	int	GuestVersion,
		int	HostVersion
	)			[virtual]

Called by KdRpcDispatcher to report protocol version mismatch.

Implements IKdComDispatcher.

Here is the call graph for this function:

void KdComDispatcher::SetKdDebuggerNotPresent

(

bool

Value

)

[inline, virtual]

Implements IKdComDispatcher.

---

Member Data Documentation

bool KdComDispatcher::KD_DEBUGGER_NOT_PRESENT [private]

unsigned KdComDispatcher::KdCompNextPacketIdToSend [private]

unsigned KdComDispatcher::KdCompNumberRetries [private]

unsigned KdComDispatcher::KdCompPacketIdExpected [private]

unsigned KdComDispatcher::KdCompRetryCount [private]

unsigned KdComDispatcher::m_PacketsGotFromLastReset [private]

unsigned KdComDispatcher::m_PacketsSentFromLastReset [private]

PipeServer<false, true, true> KdComDispatcher::m_Pipe [private]

unsigned KdComDispatcher::m_SequentialResetCount [private]

TraceAssistant KdComDispatcher::m_TraceAssistant [private]

---

The documentation for this class was generated from the following files:

• rpcdispatch/kdcomdisp.h
• rpcdispatch/kdcomdisp.cpp
