RPCTableManager Class Reference

Performs patching of GuestRPC mechanism handler table. More...

#include <tablemgr.h>

Collaboration diagram for RPCTableManager:

[legend]

List of all members.

Classes
struct	AddressRange
	Represents an arbitrary address range. More...
struct	RefGroupDescriptor
	Contains information about a set of pointers to strings that can potentially be a GuestRPC mechanism handler table. More...
struct	RPCHandlerRecord
	Represents a GuestRPC mechanism handler entry used by VMWARE-VMX.EXE. More...
struct	RPCTableInfo
	Contains information about a GuestRPC mechanism handler table. More...
struct	StringPointer
	Represents a pointer to an ASCIIZ string with a cached size. More...
struct	StringReferenceDescriptor
	Represents a pointer to a string pointer. Used to locate GuestRPC mechanism handler table with pointers to command names. More...
Public Member Functions
	RPCTableManager (HINSTANCE hThisDLL)
bool	InstallHandler (const char *pszPrefix, size_t prefixLen, GRPCHANDLER pHandler, void *pContext, bool ForceReinstall)
void	RestoreOriginalHandler ()
bool	IsEntryModified ()
Private Types
enum	{ VerifMaxStringLength = 100 }
typedef bool(*	GRPCHANDLER )(void *pContext, int ChannelNumber, char *pCommandBody, unsigned CommandBodyLength, char **ppReply, unsigned *pReplyLen)
Private Member Functions
bool	FindHandlerTable (bool FullMode=false)
	Tries to load handler table information from PatchInfoDatabase, and, if not found, scans for it.
void	DoPatch (RPCHandlerRecord *pEntry, const char *pszPrefix, size_t prefixLen, GRPCHANDLER pHandler, void *pContext)
Static Private Member Functions
static bool	PtrInRange (const std::list< AddressRange > &list, void *ptr)
static bool	islen (const char *pStr, size_t expected)
	Returns whether pStr points to an ASCIIZ string with length of exact expected bytes.
static bool	VerifyEntry (RPCHandlerRecord *pRec, std::list< AddressRange > &dataRanges, std::list< AddressRange > &codeRanges)
	Returns whether a potential GuestRPC mechanism handler entry is correct and contains no inconsisancies.
static void	FindSections (char *lpMainExe, std::list< AddressRange > &dataRanges, std::list< AddressRange > &codeRanges)
static void	MakeListOfStrings (const std::list< AddressRange > &dataRanges, BazisLib::SingleMallocVector< StringPointer > &strings, bool FullMode)
static void	FindStringRefs (const std::list< AddressRange > &dataRanges, const BazisLib::SingleMallocVector< StringPointer > &strings, BazisLib::SingleMallocVector< StringReferenceDescriptor > &stringRefs)
static void	GroupStringRefs (BazisLib::SingleMallocVector< StringReferenceDescriptor > &stringRefs, BazisLib::SingleMallocVector< RefGroupDescriptor > &groups)
static bool	ScanPotentialRPCTable (void *pAddr, std::list< AddressRange > &dataRanges, std::list< AddressRange > &codeRanges, RPCTableInfo &info)
Private Attributes
PatchInfoDatabase	m_Database
PatchingParams	m_Params
RPCHandlerRecord	m_OriginalHandler
RPCHandlerRecord	m_PatchedEntryCopy
RPCHandlerRecord *	m_pPatchedEntry

---

Detailed Description

Performs patching of GuestRPC mechanism handler table.

VMWare main process (vmware-vmx.exe) contains a table of RPC dispatchers. The RPCTableManager finds this table by building a list of all strings in the original EXE module and finding a structure containing links to the matching strings.

---

Member Typedef Documentation

typedef bool(* RPCTableManager::GRPCHANDLER)(void *pContext, int ChannelNumber, char *pCommandBody, unsigned CommandBodyLength, char **ppReply, unsigned *pReplyLen) [private]

---

Member Enumeration Documentation

anonymous enum [private]

Enumerator:

VerifMaxStringLength

---

Constructor & Destructor Documentation

RPCTableManager::RPCTableManager

(

HINSTANCE

hThisDLL

)

---

Member Function Documentation

void RPCTableManager::DoPatch	(	RPCHandlerRecord *	pEntry,
		const char *	pszPrefix,
		size_t	prefixLen,
		GRPCHANDLER	pHandler,
		void *	pContext
	)			[inline, private]

bool RPCTableManager::FindHandlerTable

(

bool

FullMode = false

)

[private]

Tries to load handler table information from PatchInfoDatabase, and, if not found, scans for it.

Here is the call graph for this function:

void RPCTableManager::FindSections	(	char *	lpMainExe,
		std::list< AddressRange > &	dataRanges,
		std::list< AddressRange > &	codeRanges
	)			[static, private]

Here is the call graph for this function:

void RPCTableManager::FindStringRefs	(	const std::list< AddressRange > &	dataRanges,
		const BazisLib::SingleMallocVector< StringPointer > &	strings,
		BazisLib::SingleMallocVector< StringReferenceDescriptor > &	stringRefs
	)			[static, private]

Here is the call graph for this function:

void RPCTableManager::GroupStringRefs	(	BazisLib::SingleMallocVector< StringReferenceDescriptor > &	stringRefs,
		BazisLib::SingleMallocVector< RefGroupDescriptor > &	groups
	)			[static, private]

Here is the call graph for this function:

bool RPCTableManager::InstallHandler	(	const char *	pszPrefix,
		size_t	prefixLen,
		RPCTableManager::GRPCHANDLER	pHandler,
		void *	pContext,
		bool	ForceReinstall
	)

Here is the call graph for this function:

bool RPCTableManager::IsEntryModified

(

)

[inline]

static bool RPCTableManager::islen	(	const char *	pStr,
		size_t	expected
	)			[inline, static, private]

Returns whether pStr points to an ASCIIZ string with length of exact expected bytes.

void RPCTableManager::MakeListOfStrings	(	const std::list< AddressRange > &	dataRanges,
		BazisLib::SingleMallocVector< StringPointer > &	strings,
		bool	FullMode
	)			[static, private]

Here is the call graph for this function:

static bool RPCTableManager::PtrInRange	(	const std::list< AddressRange > &	list,
		void *	ptr
	)			[inline, static, private]

void RPCTableManager::RestoreOriginalHandler

(

)

bool RPCTableManager::ScanPotentialRPCTable	(	void *	pAddr,
		std::list< AddressRange > &	dataRanges,
		std::list< AddressRange > &	codeRanges,
		RPCTableInfo &	info
	)			[static, private]

Here is the call graph for this function:

static bool RPCTableManager::VerifyEntry	(	RPCHandlerRecord *	pRec,
		std::list< AddressRange > &	dataRanges,
		std::list< AddressRange > &	codeRanges
	)			[inline, static, private]

Returns whether a potential GuestRPC mechanism handler entry is correct and contains no inconsisancies.

Here is the call graph for this function:

---

Member Data Documentation

PatchInfoDatabase RPCTableManager::m_Database [private]

RPCHandlerRecord RPCTableManager::m_OriginalHandler [private]

PatchingParams RPCTableManager::m_Params [private]

RPCHandlerRecord RPCTableManager::m_PatchedEntryCopy [private]

RPCHandlerRecord* RPCTableManager::m_pPatchedEntry [private]

---

The documentation for this class was generated from the following files:

• kdclient/tablemgr.h
• kdclient/tablemgr.cpp
